The VM6S-DRVH is an best buy when more Mic inputs and stereo power outputs needed.
The features and functions in a compact, easy to use format. simply add more power amps
and speakers and your ready for larger venues.
- Rugged warnex coated encloser.
- Available rack mount version 3-1/2 space.
- 6 of balanced Mic/Line Mono Input Channels.
- High Power 400W (200 +200) in a small compact package.
- 2 Band CH EQ, 1 AUX send, post EQ level Control on each channels.
- 3 band stereo master EQs low noise, no cliping design.
- DRV technology long decay time Digital Effector and foot switch jack.
- AUX input level control and recording playback RCA Jack.
- FET control Quiet power On/Off muting circuit.
- Lowest in-rush trodial X-formers and T-tunnel design heatsink cooling.
|
|
| |
| SPECIFICATIONS |
 |
|
|
| Model |
VM6S-DRVH |
| Configuration |
|
| Power(EIA) |
|
| 4 ohm load per channel |
210W + 210W |
| 8 ohm load per channel |
140W + 140W |
| Rated Power(20-20kHz) |
|
| 4 ohm load |
200W+200W |
| 8 ohm load |
135W+135W |
Distortion
(THD & SMPTE IND; 20Hz to 10kHz) |
|
| Mic input to main mixes output |
0.01% |
| Mic input to power amp output |
0.05% |
Inputs
(all 1/4" TRS are Bal./Unbal.except*) |
|
| Mono mic/line |
6 |
| Stereo line |
N/A |
| Tape In |
Stereo RCA |
| AUX In |
TS 1/4" |
Outputs
(all 1/4" TRS are Bal./Unbal.except*) |
|
| Speaker Outputs |
TS 1/4" |
| Main Mix(line)Level |
1 TS 1/4”, L,1TS 1/4” R |
| Main Mono(Subwoofer) |
N/A |
| Aux Sends |
TS 1/4", 1 EFX. |
| Tape L/R Stereo |
Stereo RCA |
| Controls Channel |
|
| AUX Send Control |
1 FX |
| Constant Pan Control |
|
| 10dB Input PAD |
N/A |
| Controls Master |
|
| Digi EFX |
Dual Variable
1 REV Control(0.5~10 sec)
1 DELAY Control(50~1000 msec)
1 FEEDBACK Control(0-90%)
1 Delay and Reverb MIXING Control(0~100%)
|
| Digi EFX Control |
On/Off, LED Level Set |
| Digi EFX Buss Control |
Yes |
| Aux In Control |
Yes |
| 7-Band Graphic Equalizer |
Yes(3 Band Type) |
| Aux Send Master |
|
| Power AMP Assign |
N/A |
| Foot Pedal EFX Jack |
Yes |
| Noise |
|
| Equivalent input noise |
-110 dB |
| Residual output noise(SP OUT) |
-70 dB |
| Residual output noise(MAIN OUT) |
-97 dB |
| Crosstalk |
|
| Adjacent inputs or input to output |
60 dB |
| Frequency Response |
|
| 20Hz to 40kHz(Mic Pre Section) |
+0,-1.5dB |
| 20Hz to 30kHz(Power Amp Section) |
+0, -1dB |
| Maximum Levels |
|
| Mic Preamp Input |
+4 dBu |
| All Other Inputs |
+18 dBu |
| Impedances |
|
| Mic Preamp Input |
4k Bal. |
| All Other input |
＞10k |
| Line Input |
4k |
| CH Equalization |
2 Band |
| Low EQ |
100Hz +/-15dB |
| Mid EQ |
N/A |
| Hi EQ |
10 kHz +/-15dB |
| Micriphone Preamp E.I.N. |
|
| 1/3 Power Requirements |
170Watts |
| Dimension(WxHxD) |
415 x 197 x 235 |
| Shipping/CBM |
0.0452 |
| Net Weight |
12.52kg |
| Shipping Weight |
14.00kg |
|
| *Note: Specifications subject to change without notice |
|
|
